AV-Link HS-S4P

The HS-Exx (P)/Sxx (P) is used mainly in TV broadcasting projects, multimedia
conference halls, and large display performances, TV teaching and command control
centers. It boasts features of power interruption protection during the power surge as
well as the digital audiovisual signal flawlessly broadcasting and zero compression
extension. The HS-Exx (P)/Sxx (P) supports a HDMI Type A for input, a HDMI Type A for
output and x4/x8/x16 HDBaseT output connectors. Besides, it also supports IR modules
for one on one or one on all IR remote control through IR Blasters or IR receivers. Better
yet, the HS-Exx (P)/Sxx (P) series even supports the “Power over Cable” functionality to
get rid of up to 4/8/16 power adapters’ annoying wirings!

• Supports 1 HDMI connector for input and 4 RJ-45 connectors for HDBaseT output interfaces.
• Supports 1 HDMI connector for output display identical image on local side.
• Easily applying a single HDMI cable and multiple CATx cables for flawlessly broadcasting and zero mpression extension.
• Supports HDMI Receiver
• - HX-SRPUW (70M) for HS-SxxP
• HDBaseT Output supports the long-distance transmission via a 70m CATx cable
• HDCP Compliant
• Supports resolution up to UltraHD 4K x 2K@30Hz, 8-bit or 1080P@60Hz, 12-bit
• Supports original 3D pass through
• Supports High Definition Audio (Dolby TrueHD, Dolby Digital Plus and DTS-HD MA)
• IR pass-through supports all IN and OUT ports
• IR pass-through supports all kinds of IR frequency band
• IR pass-through supports Bi-directional transmission between IN and OUT ports
• IR pass-through supports One way (Forward) IR (IR IN on transmitter side, and IR Out on receiver side)
• Supports IR remote control
• Supports Power over Cable
• Internal universal power supply
• 1U rack design.
