MAV Square 33" TFT LCD Monitor
SKU: 2101856
Features
- LVDS Interface with 4 pixel / clock (Jeida Format)
- High-speed response
- 0.5t Glass
- 8-bit color depth , display 16. 7M colors
- Incorporated edge type back-light (One Light Bar)
- High luminance and contrast ratio, low reflection and wide viewing angle
- DE (Data Enable) only
- RoHS/Halogen Free
- Gamma Correction
- Reverse type
Parameter | Specification | Unit | Remarks | ||
Active area | 596.16 (H) ×596.16 (V) | mm | |||
Number of pixels | 1920(H) ×1920(V) | pixels | |||
Pixel pitch | 0.1035(H) x 0.3105(V) | mm | |||
Pixel arrangement | RGB Vertical stripe | - | |||
Display colors | 16.7M | colors | |||
Display mode | Normally Black | - | |||
Dimensional outline | 612.96(H) × 612.96 (V) × 7.7(D) typ | mm | Detail refer to drawing | ||
Weight | 5.2 (Simulation) | Kg | |||
Surface Treatment | AG 25 %, 3H | - | |||
Back-light | Left side 1-LED Light bar & Right side 1-LED Light bar | - | |||
