| Panel | Screen Type | LED Backlight and LCD A Grade | Number of Colors | 16.7M(8-bit 2(LVDS) |
| Screen Size | 18.5 Inch (16:9) | Viewing Angle | (H:178° V:178°) |
| Viewing Area | 344 (H)×194 (V) | Working Life | >50000 Hours |
| Resolution | 1920x1080 | Contrast Ratio | ≥5000:1 |
| Brightness | ≥250cd/m2 | Refresh Frequency | 60Hz |
| Response Time | <5ms | | |
| Touch Panel | Touch Mode | Capacitive Touch Screen | Electrical Current/Voltage | 180Ma/DC+5V±5% |
| Response Time | <5ms | Anti-light Interference | Anti-light Interference: it can still work normally under the influence of sunlight, incandescent light, fluorescent light and some other strong lights. |
| Quantity of Touch Point | Standard Configuration: 10 Touch Points, enlarging and shrinking images is availablle, it also supports multi-touch. | Data Output | Coordinate Output |
| Touch Identification Validity | >1.5mm | Surface Hardness | Thermal Tempering, Morse magnitude 7 explosion-proof glass |
| Scanning Frequency | 200Hz | Operating System Compatibility | Windows 7/ Windows 8/CE/Mac/Android/Linux /XP |
| Scanning Accuracy | 4096×4096 | Firmware | Update is available |
| Communication Code | High Speed USB 2.0, 3.0 | Driver | Plug and Play |
| Theoretical Clicking Time | >50 Million Times Clicking | | |
| Parameter of Display | Power Supply Interface | 12V | PC-AUDIO Input | 1 |
| Comb Filter | 3D COMB filter to lower noise | Earphone Output | 1 |
| VGA Input, (15 pins D-Sub) | 1 | Power of Sound Output | 2*10W |
| HDMI Interface | 1 | Quantity of Speaker | 2 |
| DVI Interface | 1 | | |
| Power Supply Parameter | Input Power Supply | 220V AC 50/60Hz | Overall Power Consumption | <220W |
| Output Power Supply | 12V 5A | Standby Power Consumption | <3W |
|
